Electric Paint Machine 970

Airless Paint Machines

Electric Paint Machine 970

The Electric Paint Machine 970 is FlowLand's most powerful and industrially capable electric airless sprayer. Built for the most demanding professional coating applications — including large-scale industrial facilities, marine maintenance, and continuous high-volume spraying — it delivers maximum output without requiring a compressed air supply.

  • Airless
    Spray
  • High
    Pressure
  • Easy
    Maintenance
  • Wide
    Application

High-Output Airless
Spraying for Professionals

The Electric Paint Machine 970 is FlowLand's most powerful and industrially capable electric airless sprayer. Built for the most demanding professional coating applications — including large-scale industrial facilities, marine maintenance, and continuous high-volume spraying — it delivers maximum output without requiring a compressed air supply.

  • Flagship Electric
    Model
  • No Compressor
    Required
  • Industrial-grade
    Performance
  • High-pressure Airless
    Output

Technical Specifications

ModelElectric Paint Machine 970
Operating PrincipleElectric-powered airless spray
Maximum Pressure200 – 300 bar
Flow Rate1.5 – 6 l/min
Motor Power800 – 3000 W
Voltage220V / 380V
Inlet Diameter½" – 1"
Hose Length10 – 30 m
Nozzle Range0.015 – 0.035 inch
Weight20 – 60 kg

Materials

Fluid SectionStainless Steel with Tungsten Carbide balls and seats
Piston RodChrome-plated Steel
PackingsPTFE / UHMW-PE, leather
Frame / CartSteel, powder-coated
HoseHigh-pressure nylon, 250–500 bar
GunForged Aluminium, Tungsten Carbide tip

Output Curve

02468060120180240300Spray Pressure (bar)Material Output (L/min)
  • Tip 0.035"
  • Tip 0.027"
  • Tip 0.021"
  • Tip 0.015"
Indicative output by tip size; actual output depends on material viscosity and hose length.

Dimensions

Model ClassLength (mm)Width (mm)Height (mm)Weight (kg)
Portable electric48038044018–25
Cart electric64052076035–60
Pneumatic 28:1 – 30:16005601,05045–55
Pneumatic 68:17006201,25075–95

Typical dimensions for the model range; certified dimensional drawings are available on request.
