Portable Grease Drum System – SVS2400

Drum, IBC & Tank Systems

Portable Grease Drum System – SVS2400

The SVS2400 Portable Grease Drum System is available in multiple versions for different purposes — with pump options offering different output rates and pressure ratios, hose lengths up to 20 metres, and metered grease guns that can be added to the system as needed. This gives the system an extremely high work capacity. The drum trolley is made from quality sheet steel with electrostatic paint, and its two swivel and two fixed wheels ensure excellent mobility. The SVS2400 consists of 8 standard components, but you can choose your own grease pump, grease gun, and hose length.

  • Air
    Operated
  • High
    Pressure Ratio
  • Easy
    Maintenance
  • Robust
    Design

Powerful Lubrication
for Workshop and Industry

The SVS2400 Portable Grease Drum System is available in multiple versions for different purposes — with pump options offering different output rates and pressure ratios, hose lengths up to 20 metres, and metered grease guns that can be added to the system as needed. This gives the system an extremely high work capacity. The drum trolley is made from quality sheet steel with electrostatic paint, and its two swivel and two fixed wheels ensure excellent mobility. The SVS2400 consists of 8 standard components, but you can choose your own grease pump, grease gun, and hose length.

  • Multiple
    Configurations
  • Metered Gun
    Compatible
  • Quality Steel
    Trolley
  • 4-wheel
    Mobility

Technical Specifications

Pneumatic Grease Pump2400
Grease Gun2305
Grease Z-Swivel Joint2405
Drum Lid2085
Oil Pressure Weight2620
Oil Pressure Plate2621.185
Drum Trolley2410
Hose5 m
Warranty36 Months

Materials

Air Motor BodyDie-cast Aluminium
Pump TubeSteel, zinc-plated
Piston & RodHardened Steel, chrome-plated
SealsNBR / PU
Follower Plate & CoverSteel, powder-coated
HoseRubber, steel-reinforced, R2

Delivery Curve

03006009001,2001,5000246810Hose Length (m)Delivery (g/min)
  • 8 bar air
  • 6 bar air
  • 4 bar air
Indicative delivery through a ¼" hose at 4–8 bar air inlet pressure and 20 °C, NLGI 2 grease; longer hoses and colder lubricant reduce output.

Applications

  • Vehicle and truck workshops
  • Agricultural and construction machinery service
  • Industrial maintenance departments
  • Mining and quarry equipment
  • Marine and port equipment
  • Centralised lubrication stations

Downloads
