Cleaning & Washing
Parts Washing Machine 80 L – 9200
The Model 9200 Pneumatic Parts Washing Machine is ideal for cleaning small engine components, vehicle parts, and machine tool parts that have been removed from vehicles and machinery. It features an 80-litre tank capacity and a 45-litre washing tray. Four wheels (2 fixed + 2 swivel) provide excellent mobility around the workshop.
- High
Pressure - Chemical
Resistant - Ergonomic
Grip - Robust
Design
Industrial Cleaning
and Washing Equipment
The machine is very simple to use and requires water-based solvent. Tank draining is performed pneumatically, and a safety valve on the tank protects against excessive air pressure. It can also be used temporarily without a continuous air connection, using the immersion method. A cleaning brush and an air gun for quick drying are included. Fluid level is monitored via a tank scale, and a drain plug allows removal of solid waste from the tank.
- Pneumatic
Operation - Immersion Method
Compatible - Cleaning Brush
Included - Safety
Valve
Technical Specifications
| Model | 9200 |
|---|---|
| Operating Type | Pneumatic (Air-Operated) |
| Drain Pressure | 0.5 bar |
| Tank Capacity | 80 L |
| Washing Tray Capacity | 45 L |
| Hose Length | 1.5 m |
| Hose Size | 3/4" |
| Wheels | 2 fixed + 2 swivel |
| Packaging Dimensions | 58 x 61 x 103 cm |
| Weight | 40 kg |
| Warranty | 36 Months |
Materials
| Body | Brass or Stainless Steel |
|---|---|
| Grip | Glass-fibre reinforced polymer |
| Seals | NBR / FKM |
| Lance | Stainless Steel |
| Tank (washing machines) | Steel sheet, powder-coated |
Applications
- Vehicle wash bays
- Industrial parts cleaning
- Food and beverage plants
- Marine and offshore cleaning
Dimensions
| Type | Inlet | Length (mm) | Weight (kg) |
|---|---|---|---|
| Trigger wash gun | ⅜" BSP F | 240 | 0.6 |
| Triggerless gun | ⅜" BSP F | 220 | 0.5 |
| Foam / liquid spray gun | ¼" BSP | 260 | 0.8 |
| Telescopic foam gun | ¼" BSP | 900–1,800 | 1.6 |
| Parts washer 80 L | — | 1,000 × 600 × 1,000 | 45 |
Typical dimensions for the model range; certified dimensional drawings are available on request.
